The Marlin 8 is a confidence-boosting trail bike with updated geometry that gives you more control on singletrack without skipping on features for everyday use, like mounts for racks and a kick stand. It's built for years of progress thanks to 12-speed SRAM shifting and an upgraded RockShox air-spring suspension fork.
Checkout & Specifications
Frame
Alpha Silver Aluminum, internal derailleur & dropper post routing, rack and kickstand mount, 135x5mm ThruSkew
*Fork
Size: S RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel Size: M , ML , L , XL RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel Max compatible fork travel 120mm, XXS: 80mm
Hub front
Formula DC-20 LW, alloy, 6-bolt, 5x100 mm QR
Hub rear
Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear
Bontrager Switch thru axle
*Rim
Size: S Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve Size: M , ML , L , XL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve *Tyre Size: S Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 27.5x2.40" Size: M , ML , L , XL Maxxis Ardent, tubeless ready, EXO casing, folding bead, 60tpi, 29x2.40" Max tyre size Frame: 29x2.40" (XXS: 26x2.40", XS & S: 27.5x2.40"), Fork: See manufacturer
Shifter
SRAM SX Eagle, 12-speed
Rear derailleur
SRAM SX Eagle
*Crank
Size: S , M SRAM SX Eagle, 30T steel ring, 49 mm chainline, 170 mm length Size: ML , L , XL SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length Bottom bracket Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle Cassette SRAM PG-1210 Eagle, 11-50, 12-speed Chain SRAM SX Eagle, 12-speed Pedal VP-536 nylon platform Max. chainring size 1x: 34T, 2x: 36/22
Saddle
Bontrager Arvada, steel rails, 138 mm width
*Seatpost
Size: S TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length Size: M TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length Size: ML , L , XL TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length
*Handlebar
Size: S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width Size: M , ML , L , XL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width Grips Bontrager XR Trail Comp, nylon lock-on
*Stem
Size: S Bontrager Comp, 31.8 mm, 7-degree, 35 mm length Size: M , ML , L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length Size: XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length Head set Semi-integrated, 1-1/8" Brake Shimano MT200 hydraulic disc
*Brake rotor
Size: S , M , ML , L , XL Shimano RT26, 6-bolt,160 mm Size: M , ML , L , XL Shimano RT26, 6-bolt,180 mm
